TRA58434-4 TRAXXAS Slash 2WD Brushless Short Course Truck - 40th Anniversary Edition
THIS ITEM DOES NOT QUALIFY FOR FREE SHIPPING
Note: Graves RC Coupons are not applicable with this product
Description
Traxxas Slash® has defined short course RC racing for a generation. Now there’s a new Slash with even more power and performance. Slash’s new Velineon® 3s brushless power system transforms 11.1 volts of LiPo power into incredible 50+ mph speed with a new aerodynamic body to reduce high-speed lift. A new low-CG chassis delivers razor-sharp handling with revised suspension tuning for an ultra-plush ride. From the street to the track, Slash 2WD Brushless renders an authentic short course racing experience like nothing else.







Replica Short Course Wheels and Tires - Slash's replica BFGoodrich Mud Terrain T/A tires offer excellent grip in the dirt and just the right amount of slide on pavement. A new ultra-soft rear compound enhances road handling and reduces traction rolling. Their authentic scale appearance and realistic performance add to the racing experience.

Velineon V3200 Motor - Designed for 3-cell LiPo batteries, the V3200 motor is optimized for extreme power and efficiency with a large 5 mm output shaft. Ultra-high temperature sintered Neodymium magnets provide massive torque and linear power. The unique low-maintenance design features high-speed ball bearings and an integrated cooling fan for consistent power, run after run.

3-Channel TQi Sport Receiver - The TQi Sport receiver is compatible with all TQi and TQi Sport transmitters. A built-in failsafe returns the throttle to neutral and holds the steering in the last known position in the event of a signal loss.

Rugged Shock towers - Slash's rugged shock towers minimize flex and provide a rigid mounting point for the body. Reducing flex allows the suspension to soak up bumps without upsetting the chassis for a smooth and controlled ride.

Waterproof Electronics - Your RC experience should be filled with fun and adventure, not limited by the electronics. Slash's new receiver box is molded into the chassis for increased strength. A patented O-ring seal keeps water out, giving you the freedom to live out your wildest adventures, regardless of the weather.

Extreme Heavy-Duty Driveshafts - Slash's Extreme HD driveshafts are beefed up in critical areas to handle the outrageous power of the Velineon 3s brushless power system. The large-diameter half shafts offer excellent articulation and suspension travel while putting massive torque to the ground.

Long-Wheelbase Chassis - Slash's 13.2" wheelbase chassis provides superior stability on high-speed straights. A new carbon-look material gives the low-CG chassis a high-tech look to match its legendary performance.

VX3 Electronic Speed Control - The fully waterproof VX3 ESC transforms 11.1 volts of LiPo power into 60+ mph performance with the simplicity of Traxxas EZ-Set one-button programming. A large aluminum heat sink with cooling fan keeps temperatures down for longer run times. The VX3 comes loaded with high-tech features like race-inspired High-Resolution Linear Braking and real-time telemetry via Traxxas Link (requires TQi transmitter with installed wireless module).

Clipless Battery Strap - Slash holds batteries securely in place with the convenience of a rugged clipless battery strap. Swing the heavy-duty strap up and out of the way to swap batteries. Once loaded, just snap the tab into the latch and your battery stays secure until you release it.

Metal Gear Servo - Slash features a new metal-gear servo with the durability on an all-metal gear train. The new servo delivers quick, precise control with the security and convenience of fully waterproof construction.

Bellcrank Steering - Slash's high-performance bellcrank steering system nearly eliminates bump steer for precise wheel placement and increased cornering stability. A cam-operated servo saver increases steering precision while protecting the servo againts impacts.

Chassis Nerf Bars - Tough integrated nerf bars offer side chassis protection against the fender-to-fender impacts of track competition and backyard bashing.

Heavy-Duty Suspension Arms - Slash's heavy-duty suspension arms are molded in a new high-tech tray color from our toughest composite material to provide just the right amount of flex to resist breaking. The suspension arms stand up to even the most punishing drivers for non-stop action.

Steel Front Tie Bar - A steel front tie bar provides additional strength to keep the suspension in perfect alignment and protect against impacts.

Hex Hardware - Slash's hex-drive hardware provides a more positive and secure connection than other fasteners. The black-oxide coating provides a rust resistant high-tech look and feel.

Clipless Body Mounting - High-flying stunts won't upset Slash's tough clipless body. Locking tabs hold the body tightly, but release in just seconds. Slash's hidden latching system maximizes convenience and scale realism by removing traditional body clips which would interrupt the body's clean lines.

Scale Front and Rear Bumpers - Slash's front and rear bumpers mount solidly to reinforced bulkheads to absorb impacts. The tube-style bumpers offer rugged protection while looking the part of a true short course race truck. Slash's front bumper also features bosses to mount accessory LED lights.

Adjustable Steel Turnbuckles - Heavy-duty steel turnbuckles allow trackside camber and toe tuning for greater agility and high-speed performance. Captured rod ends provide unmatched durability, and they won't pop off during a race.

Extreme HD Components - Engineered for maximum strength, Extreme Heavy-Duty components fortify Slash with a full complement of driveline and suspension upgrades designed to work together as a complete package. Slash sets a new standard for durability at skate parks, racetracks, and backyards.

Magnum 272 Transmission - The Magnum 272 transmission features all metal gear internals riding on ultra-smooth sealed ball bearings. The sealed gearbox protects the transmission components from dirt and rocks.

32-Pitch Gearing - Slash is built for extreme power with a large 5mm motor output shaft and 32-pitch pinion and spur gears. Nearly 1.5x larger than standard 48-pitch gears, Slash's 32-pitch gears deliver maximum durability with reliable, long-lasting performance.

Torque-Control Slipper Clutch - The Torque-control slipper clutch uses special semi-metallic friction material and finned aluminum allow pressure plates to dissipate heat and provide consistent traction control. Spur gears can be removed and replaced without altering the slipper adjustment.

Rubber-Sealed Ball Bearings - Rubber-sealed bearings offer the ultimate in super low-friction performance and maximum protection in dusty environments. They are used in all exposed locations on the truck and are virtually maintenance free.

Steel-Composite Planetary Gear Differential - The composite planetary gear differential features a steel ring gear for long life. It uses hardened steel internal gears for maximum strength during rigorous off-road bashing. This type of differential requires virtually no maintenance, and its efficient design puts maximum tire-shredding torque to the wheels.
Model Specifications


| Name: | Slash 2WD Brushless |
|---|---|
| Type: | Short Course Truck |
| Speed: | 35+ mph with 2-cell LiPo, 50+ with 3-cell LiPo |
| Skill Level: | 1 |
| Scale: | 1/10 |
| Weight: | 5.82 pounds (2.41 kg) |
| Length: | 22.4 inches (568 mm) |
| Width: | 11.65 inches (296 mm) |
| Track: | 11.65 inches (296 mm) |
| Height: | 7.6 inches (193 mm) |
Motor Specifications

| Name: | Velineon V3200 (patent pending) |
|---|---|
| Motor Type: | Sensorless brushless |
| Weight: | 7.48 ounces (212 g) |
| Length: | 3.15 inches (80 mm) |
| Diameter: | 1.53 inches (39 mm) |
| Shaft Size: | 5 mm |
| Connector Type: | 3.5 mm Bullet |
ESC Specifications

| Name: | VX3 Electronic Speed Control |
|---|---|
| ESC Type: | Brushless |
| Voltage Range: | 2-cell or 3-cell LiPo (NiMH not supported) |
| Case Size: | 2.40″ (61 mm) x 2.09″ (53 mm) x 1.69″ (43 mm) |
| Weight: | 4.20 ounces (119 g) |
| BEC Voltage: | 6.0 volts |
| Motor Connectors: | 3.5 mm Bullet |
| Battery Connectors: | Traxxas High-Current Connector |
Features
- 35+ mph with 2s LiPo. 50+ mph with 3s LiPo (no gearing change required)
- NEW Aerodynamic Clipless Short Course Body
- Increases downforce at high speeds
- Body reinforcements help prevent pull-through damage
- Holds tight for intense action
- Quick and easy removal
- Smooth appearance with no body posts or clips
- NEW Velineon® VX3 Waterproof Electronic Speed Control
- Large aluminum heat sink with cooling fan
- Three programmable drive profiles
- Sport Mode - forward / brake / reverse
- Race Mode - forward / brake
- Training Mode™ - 50% forward / brake / 50% reverse (patented)
- Traxxas EZ-Set® one-button setup
- Telemetry capable with optional accessories
- High-Resolution Linear Braking
- Compatible with 2s and 3s LiPo batteries (NiMH not supported)
- NEW Velineon V3200 Brushless Motor
- Ultra high-temperature sintered Neodymium magnets provide massive torque and linear power
- 3200 Kv optimized for power and efficiency in 1/10th scale vehicles
- 5 mm output shaft
- Internal cooling fan for longer run times
- Low-maintenance design
- Efficient, high-speed ball bearings
- Extreme Heavy-Duty Parts Installed
- Caster blocks, axle carriers, and steering blocks beefed up with extra material
- HD suspension arms
- Extreme HD driveshafts
- Extra material for improved strength
- NEW TQi™ Sport 2.4 GHz 2-Channel Radio System with TSM®
- Removable grip adapter for smaller hands
- High-output signal delivers outstanding range
- Simple one-button programming
- 30-model memory
- 3-channel micro receiver with fail-safe security
- NEW integrated watertight receiver box with O-ring sealed cover
- Traxxas Stability Management (TSM)
- Improves straight line acceleration and braking on low-traction surfaces
- Maintains steering composure to allow throttle-on powerslides
- Never dulls throttle or slows the truck
- Activated or deactivated directly from the transmitter
- NEW Clipless Battery Compartment
- Rugged battery strap latches shut to secure batteries
- No battery clips to lose
- Accepts many 2s and 3s battery configurations
- NEW Low-CG Chassis
- Battery and electronics sit low for improved handling
- Dramatically improved corner speed and stability
- Reinforced to reduce flex under load
- Carbon-fiber texture for a high-tech look and feel
- Tough tube bumpers and nerf bars to protect the chassis
- Long 13.2″ wheelbase for increased stability
- Steering
- NEW 2057 waterproof, metal-gear servo
- Full metal gear train for improved durability
- NEW Dual bellcrank design with integrated servo saver
- Transmission and Driveline
- Magnum 272™ metal-gear transmission
- Torque-Control™ slipper clutch system
- NEW 32-pitch spur and pinion gear
- Planetary gear differential with steel ring gear
- Sealed gearbox protects the transmission with beefed up motor guard
- External gear cover with easy clutch access
- Suspension
- NEW Composite GTR Shocks
- Threaded shock collars for precise ride height adjustment
- Large oil capacity for consistent damping
- Spring retainers secured with screws
- White powder-coated springs
- 3.5 mm shaft
- Adjustable steel turnbuckles
- Captured rod ends won't pop off
- NEW steel front tie bar
- Wheels and Tires
- Pre-glued Replica BFGoodrich® Mud Terrain T/A® tires
- Performance foam inserts
- Softer rear tires for improved handling dynamics
- 2″ outer diameter, 3″ inner diameter dual-profile black split-spoke wheels
- Rubber-Sealed Ball Bearings
- Precision Hex Hardware
- Battery and Charger Sold Separately
In The Box
- Slash 2WD short course truck with VX3 ESC and V3200 motor
- TQi Sport 2.4 GHz radio system
- High quality maintenance tools
Needed to Complete
- Batteries
Slash 2WD Brushless requires a single 2-cell or 3-cell LiPo battery.
- Charger
The Traxxas EZ-Peak® charger 2970 is recommended for easy and fast charging performance.
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter.
Additional Information
Oversized Item: |
Yes |
Model Type: |
Truck |
Model Type: |
Short Course |
Drive: |
2WD |
Completeness: |
RTR-Ready to Run |
Power: |
Electric |
Scale: |
1/10th |
