TRA108076-1-C TRAXXAS Mini XRT VXL-3s
THIS ITEM DOES NOT QUALIFY FOR FREE SHIPPING
Note: Graves RC Coupons are not applicable with this product
Description
Extreme 3s Performance. Compact Size.
Mini XRT® is a true rocket with full 1/10 scale Velineon® 3s brushless power in a compact, take-anywhere size. Mini XRT lives up to its name with unprecedented 55+ mph speed and ferocious acceleration, backed by race-inspired engineering and unrivaled toughness. Mini XRT shatters all expectations with big-scale performance and toughness that fits in a backpack.
Bred For Performance - Like its X-series™ counterpart, Mini XRT was engineered with maximum focus on speed, handling, and performance. A low, ultra-wide stance delivers supreme confidence and control as Mini XRT muscles its way to 55 mph and beyond. It’s a whole new way to experience big-scale fun and toughness in a backpack-friendly size.
Extreme 1/10 Scale Brushless Power - The Velineon VXL-3s brushless power system is the heart of Traxxas’ fastest and most powerful 1/10 scale vehicles. For the first time ever, this extreme 11.1-volt powerplant now comes installed in a compact platform. The result is astonishing acceleration, 55+ mph speed, and wheel-standing power at any rpm.
1/10 Scale 4X4 Driveline - Adding 3s Velineon power to a compact platform requires bold engineering. Mini XRT comes outfitted with the proven driveline components of Traxxas’ toughest 1/10 scale 4X4 trucks. Front, center, and rear steel-gear differentials, along with 32-pitch gearing and HD driveshafts, far exceed requirements for strength and long life.
Maxx Chassis Technology - Mini XRT is the newest truck to use the revolutionary chassis design pioneered in Mini Maxx®. Perfectly sized to fit into a backpack, Mini XRT transforms full-scale performance and durability into a supremely compact chassis. Just one look at the rigid, unified structure and you know it’s built Maxx tough.
Clipless Body with Cooling Vents - Mini XRT’s innovative clipless body is rock solid and easy to use. Just drop the body onto the chassis and snap it into place for a secure hold. When it’s time to change the battery, depress the tabs under the wheel wells and lift to access the chassis. Nothing else is faster or latches more securely.
WideMaxx Suspension - Mini XRT relies on proven WideMaxx® suspension design to deliver sure-footed grip and laser-focused handling. Mini XRT sits low and wide for hard cornering and maximum stability at speed. The long-travel suspension delivers refined damping control to maintain composure over the roughest terrain.
Details
Interlocking Skid Plates - Anything that flies must come down eventually so Mini XRT uses tough skid plates to absorb hard landings and protect the chassis. The interlocking skid plates fit tightly together to form a smooth, snag-free undertray. They're also quick and easy to replace as wear builds up so there's no need to hold back.
Heavy-Duty Suspension Components - Mini XRT punches well above its size class with heavy-duty suspension components engineered for maximum strength and durability. Modeled after the Maxx, the caster blocks, steering blocks, and axle carriers feature incredibly robust construction, double-shear connections, and extra reinforcing where it's needed.
Sealed Bearings - Mini XRT utilizes large, sealed bearings throughout the driveline to keep out grime and grit. Less downtime for cleaning and maintaining bearings means more run time - and more fun!
32-Pitch Gears - Mini XRT is engineered for Velineon 3s power right from the start with huge 32-pitch pinion and spur gears. Normally found in much larger 4x4 vehicles, 32-pitch gears deliver total reliability no matter how much brushless power you pour on.
Center Differential - Mini XRT's sealed center differential absorbs driveline shocks to improve driveline durability and allow performance tuning. The sealed differential comes pre-loaded with thick silicone oil to prevent unloading of the front tires for rock-steady power delivery.
Extreme-Duty Driveshafts - Mini XRT's driveshafts are 50% larger than the standard 1/16th scale driveshafts for hard launches with big 3s Velineon brushless horsepower. The oversized telescoping half shafts allow the WideMaxx suspension arms to articulate fully without binding to keep constant power flowing to the wheels.
1/10 Scale Planetary Differentials - Mini XRT's differentials are nearly twice the size of standard 1/16 scale differentials for bombproof durability. The sealed design allows you to tune the amount of locking action by varying the viscosity of the fluid inside the differentials.
XRT Wheels with Gravix Tires - Gravix tires are an evolutionary hybrid design with densely packed biting edges and sipes. They deliver outstanding grip on hard-packed surfaces along with fast and quiet-running precision. New 2.6" dual-profile graphite gray wheels provide extra clearance for suspension components and give Mini XRT a tough, menacing appearance.
Functional Rear Wing - The functional rear wing reduces drag while still providing valuable downforce for high-speed stability. The sing mounts directly to the frame for maximum strength and long-lasting durability.
Wheelie Bar - A wheelie bar is mandatory equipment on a vehicle with the power and speed of Mini XRT. The reinforced wheelie bar protects the wing and body during 100-foot wheelies and also makes a convenient carry handle.
Chassis Nerf Bars - Tough nerf bars protect the chassis from side impacts and provide additional side support to hold the body firmly in place.
Body Reinforcements with High-Pressure Cooling Vents - Mini XRT's molded body reinforcements look great and provide rugged protection for the body. Dual high-pressure air intakes are neatly integrated for a clean high-tech look. The intakes direct cooling air over the motor and speed control to keep temperaturs in check.
Rugged Protection - A rugged, impact-absorbing front bumper helps to protect the chassis from frontal impacts. The high approach angle design integrates neatly with front skid plate to allow Mini XRT to fly up and over obstacles with ease.
1/10 Scale Ultra Shocks - Mini XRT uses the same full-size oil-filled Ultra Shocks found on Traxxas 1/10 scale monster trucks for truly bottomless suspension travel. The Ultra Shocks' large oil capacity and rugged design soaks up big jumps and off-road abuse for smooth driving performance. They are easy to tune with a wide range of available oils, springs, and pistons.
Modular Chassis - Mini XRT's high-tech modular chassis features front and rear bulkheads that remove easily with just a few screws. In less than a minute using a power screwdriver, you'll have full access for easy service and adjustment.
Fixed Gear Mesh System - A fixed gear mesh system takes the guesswork out of setting your gear mesh with multiple preset gearing positions. Insert the motor screw through the desired gearing position for a perfect gear mesh every time. The fixed positioning also keeps the gear mesh tight, even after the harshest impacts.
Velineon 3500 Motor - A sensorless Velineon 3500 Kv motor delivers extreme performance with nearly zero maintenance. Ultra high-temperature neodymium magnets, high-speed bearings, and a precision, 4-pole balanced rotor deliver smooth running and long life.
VXL-3s ESC - The waterproof Velineon VXL-3s speed control is packed with technology to deliver maximum power. Large heat sink, integrated on/off switch, and three programmable drive profiles top the feature list. Two-stage low voltage detection allows full LiPo compatibility, including powerful 11.1-volt 3s packs.
Battery Compartment -A deep battery compartment shields the battery from impacts inside the reinforced chassis. A swivel clip hold-down firmly secures the battery in place for fast and easy battery swaps.
Waterproof Electronics - Your RC experience should be filled with fun and adventure, not limited by the electronics. Traxxas' patented waterproof technology gives you the freedom to live out your wildest adventures, regardless of the weather.
TQi Receiver with Fail-Safe Security - In the event of signal loss due to an accidental transmitter switch-off or depleted batteries, the receiver automatically returns the throttle to neutral and holds the last commanded steering position. The fail-safe programming is conveniently built-in and does not need to be activated.
Dual Bellcranks with Servo Saver - Mini XRT's standard-size 2075X metal-gear steering servo uses dual bellcranks for zero bump steer geometry and high-speed steering precision. Oversize components and double-shear connections make Mini XRT unbelievably tough with a cam-style servo saver for added protection against impacts.
WideMaxx Suspension Arms - WideMaxx suspension arms add 20mm extra width to the Mini XRT's stance for improved stability and handling. The double-wishbone design maintains proper suspension geometry throughout the entire range of travel. Modeled after the Maxx monster truck, their double-shear connections and beefy construction maximize strength and durability.
Hex Hardware - Hex-drive hardware provides a more positive and secure connection than other fasteners. The black-oxide coating provides a rust resistant high-tech look and feel.
Model Specifications
| Model Name: | Mini XRT |
|---|---|
| Model Type: | Monster Truck |
| Top Speed: | 55+ |
| Skill Level: | 1 |
| Scale: | Mini |
| Length: | 14.8 inches (376 mm) |
| Width: | 11 inches (279 mm) |
| Height: | 5 inches (127 mm) |
| Weight: | 3.99 pounds (1.81 kg) |
| Front Track: | 11 inches (279 mm) |
| Rear Track: | 11 inches (279 mm) |
Motor Specifications
| Motor Name: | Velineon® 3500 |
|---|---|
| Motor Type: | Sensorless brushless |
| Motor Weight: | 9.24 ounces (262 g) |
| Motor Length: | 3.03 inches (77 mm) overall length, 2.2 inches (56 mm) can length |
| Motor Diameter: | 1.41 inches (36 mm) |
| Motor Shaft Size: | 3 mm |
| Motor Connector Type: | 3.5 mm bullet |
ESC Specifications
| ESC Name: | VXL-3s electronic speed control |
|---|---|
| ESC Type: | Brushless |
| ESC Case Size: | 1.54 inches (39 mm) / 2.18 inches (55 mm) / 1.30 inches (33 mm) |
| ESC Weight: | 3.17 ounces (90 g) |
| Motor Connectors: | 3.5 mm bullet |
| Battery Connectors: | Traxxas High-Current Connector |
| ESC Power Wire: | 12 gauge Maxx Cable |
Features
- 40+ mph with included 2-cell LiPo Battery
- 55+ mph with optional 3-Cell LiPo Battery (sold separately)
- Clipless Body Mounting System
- Quick and easy installation and removal
- Nerf bar channels for side body support
- Reinforced for extra protection against tearing
- Functional rear wing
- VXL-3s™ Waterproof Electronic Speed Control
- Three programmable drive profiles
- Sport Mode - forward / brake / reverse
- Race Mode - forward / brake
- Training Mode™ - 50% forward / brake / 50% reverse
- Heat sink accepts accessory cooling fan (3340)
- Traxxas EZ-Set® one-button setup
- Built-in two-stage low-voltage detection
- Velineon® 3500 Kv Brushless Motor
- Ultra high-temperature sintered neodymium magnets
- Low-maintenance design
- Precision-balanced rotor
- Efficient high-speed ball bearings
- 3500 Kv
- Brilliant blue-anodized finish
- Battery and Charger Included
- High-capacity 2-cell LiPo battery
- 7.4 volts
- 3500 mAh for extended run time
- 2-amp USB-C charger
- iD® technology for faster, safer charging
- TQi™ 2.4 GHz High Output 2-Channel Radio System
- Programmable multi-function knob
- Adjustable steering and throttle percentage (dual rates)
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle end points
- 5-channel micro receiver (6533) with fail-safe security
- Patented waterproof receiver box with easy-access plug
- Traxxas Stability Management® (TSM)
- Improves straight line acceleration and braking on low-traction surfaces
- Maintains steering composure to allow throttle-on powerslides
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
- 1/10 Scale 4X4 Drivetrain
- Full-time shaft-driven 4-wheel drive
- 1/10 scale extreme-duty telescoping driveshafts
- Direct-drive (no transmission)
- Sealed center differential
- Large 32-pitch gears
- Sealed planetary steel-gear differentials (F&R)
- Fixed gear mesh system
- Modular Composite Chassis
- Modular chassis with interlocking front and rear bulkheads
- Absorbs and distributes impact energy
- Driveline is sealed in the chassis to keep out dirt
- Easy to service and access components
- Easy Battery Access
- Battery is protected deep in the chassis
- Battery hold-down pivots for easy access
- More secure than conventional retention systems
- Steering
- 1/10 scale 2075X waterproof high-torque, metal-gear servo
- Heavy-duty double-shear bellcranks
- Cam-operated servo saver
- Suspension
- Heavy duty, double-shear suspension arms
- Dual wishbone design
- Extra tough outer suspension components
- Oil-Filled Ultra Shocks™
- Full size 1/10 scale shocks
- Large oil capacity
- Easy to tune
- Bumpers and Skid Plates
- Tough energy absorbing front bumper
- High-angle front skid plate
- Rugged interlocking skid plates
- Smooth undertray eliminates snags
- Integrated nerf bars for side impact resistance
- Wheels and Tires
- New graphite gray mini XRT wheels
- Gravix® tires with foam inserts
- Excellent traction on or off the road
- Directional tread pattern for quieter running
- Thick center carcass resists ballooning
- Hex Hardware with Rust-Resistant Black Oxide Coating
- Sealed Ball Bearings
What's in the Box?
- Mini XRT Ready-To-Race monster truck
- Velineon VXL-3s brushless power system
- 3500 mAh 2-cell LiPo battery
- 2-amp USB-C charger
- Quick Start Guide
- TQi 2.4 GHz radio system
- High quality maintenance tools
What You'll Need to Complete?
- AA Alkaline Batteries
Four AA alkaline batteries for the transmitter
- Charging Accessories
Power adapter 2912 and power cable 2916 recommended for peak charging performance
Additional Information
Oversized Item: |
Yes |
Model Type: |
Monster Truck |
Power: |
Electric |
Scale: |
1/14th |
Drive: |
4WD |
