Description
AXI03028 AXIAL 1/10 SCX10 PRO Scaler 4WD Kit
THIS ITEM DOES NOT QUALIFY FOR FREE SHIPPING
Note: Graves RC Coupons are not applicable with this product
Features
- The easiest, most convenient way to build a scale crawler for competition, with numerous innovations never before offered in a single comp-ready kit.
- Pro kit saves significant time and money compared to buying components separately.
- Comp-ready chassis is lighter, lower, and more adjustable, optimizing performance for climbing, side hilling, and break over.
- Multi-piece steel tube axles can accommodate a servo on the axle (AMS) or chassis-mounted (CMS).
- Low and forward motor position provides superior weight distribution and improves balance.
- Underdrive the rear axle via servo or manually lock the rear axle in 1:1 or underdrive.
- New aluminum smooth body, oil-filled shocks provide higher clearance.
- The Pro has already won and placed at multiple events with designer Wyatt Mellon at the wheel.
In The Box
- (1) SCX10 Pro Kit
- (1) Product Instruction Manual
Needed to Complete
- (1) 2- to 4-Channel Surface Transmitter & Receiver
- (1) Rock Crawler Motor
- (1) Electronic Speed Control
- (1) Steering Servo
- (1) Body for SCX10 Pro Chassis
- (4) Wheels with 12mm Hex
- (4) Tires to Fit Wheels
- (1) Micro servo for optional use of shift-able underdrive
Specifications
| Charger | Sold Separately |
| Differential | Locked |
| Receiver | Sold Separately |
| Shock Type | 2.9" - 3.8" (74-96mm) Aluminum Oil filled |
| Approximate Assembly Time | 5-7 Hours |
| Body | Not Included |
| Brakes | Integral with ESC |
| Pinion | 13T |
| Scale | 1/10 |
| Product Width | 9.25" (235 mm) |
| Radio | Sold Separately |
| Chassis | Aluminum Plate |
| Completion Level | Kit |
| Drivetrain | 4WD |
| Product Height | 7" (178 mm) |
| Wheel Hex Size | 12mm |
| Steering Type | 2WS |
| Product Length | 16.65" (423 mm) |
| Motor Size | 540/550 recommended |
| Internal Gear Ratio | 10.26:1, 15.33:1 |
| Final Drive Ratio | 38.46:1, 57.50:1 |
| Suspension | 3-Link/4-Link |
| Ground Clearance | 2.25" (57.1mm) |
| Battery | Sold Separately |
| Wheelbase | 12.5" (318 mm) |
| Product Weight | 3lbs (1.4kg) Without Components |
| Vehicle Type | Rock Crawler |
| Power Type | Electric |
| Gear Pitch | 32-Pitch |
| Servos | Sold Separately |
| Speed Control | Sold Separately |
| Ball Bearings | Complete Vehicle |
Additional Information
Car/Truck Type: |
Crawler |
Car/Truck Type: |
Off Road Truck |
Car Scale: |
1/10th |
Car Drive Type: |
4WD |
Car Completeness: |
Kit-Requires Completion |
Car, Truck Power: |
Electric |
