Description
SPMXAM4700 SPEKTRUM Avian 4250-800Kv Outrunner Brushless Motor
View AllClose
Note: Graves RC Coupons are not applicable with this product
""
Take to the Skies with Spektrum Avian Brushless Motors for Fixed-wing Models
The combination of superior performance, high reliability and user-friendly features makes the Spektrum Avian Brushless Motors an excellent choice for your next aircraft project. Plus, the wide selection means there's Avian Brushless motor that's ideal for whatever the application, including brushed-to-brushless upgrades as well as combustion-to-electric conversions. Equip your airplane with an Avian motor to compliment your Smart Technology equipped models!
Benefits
- Rapid Acceleration and Extreme Torque: Expertly engineered to deliver fast, smooth and precise acceleration and power.
- Reliable and Virtually Maintenance-free: Equipped with double-shielded sealed bearings, precision balanced motor bell and gold-plated bullet connectors.
- Excellent Cooling: Engineered to help airflow move through the motor for efficient cooling during and after flight.
Features
- Lightweight design
- Powerful and durable Rare-Earth Neodymium magnets
- 14-pole stator for smooth and precise propulsion
- Includes all required hardware: preinstalled gold plated bullet connectors, aluminum motor mount, prop adapter and female ESC connectors
- Perfect match for the Spektrum Smart Avian 45 amp ESC
- Perfect electric conversion upgrade for .32 size glow combustion power systems
Specifications
- Recommended Voltage Range – 11.1-14.8V / 3-4S LiPo
- Recommended Propeller Range – 12x6 to 13x8 Electric Prop
- Recommended Model Flying weight – 3D 1845g (4 lbs) - Sport 2950g (6.5 lbs)
- Max Wattage – 600w
- Max Current – Max Burst Amps (50A) Max Continuous Amps (45A)
Product Specifications
| Application | Sport airplanes up to 6.5lbs (2950g) and 3D airplanes up to 4lbs (1814g) |
| Connector Type | 4mm Bullet |
| Input Voltage | 11.1-14.8V (3-4S LiPo) |
| Maximum Burst Current | 1480W |
| Maximum Continuous Current | 925W |
| Motor Type | Brushless |
| Outer Diameter | 1.7" (43 mm) |
| Product Length | 2" (51 mm) |
| Product Weight | 7oz (198g) |
| Recommended Prop Range | 12x6 - 13x8 electric |
| RPM/Volt (Kv) | 800 |
| Shaft Diameter | 0.2" (5 mm) |
| Shaft Length | 0.67" (17 mm) |
Additional Information
Motor Kv: |
501 to 1,000Kv |
Motor ESC Amps: |
35 to 59A |
Motor Voltage: |
7.4 to 14.7V |
Motors: |
Motor |
