Great Planes Escapade Sport GP/EP ARF 52.5"

This is the radio controlled, glow or electric powered, almost ready to fly Great Planes Escapade Sport Airplane.

Features:

• Construction: Balsa and ply
• Covering: Covered in Top Flite MonoKote
• Wings: One-piece with aluminum joiner tube
• Aileron Control: Modeler's choice of single or dual servo control
• Radio Compartment: Plywood reinforced
• Canopy: Single tinted, hatch attaches to fuselage with magnets, preinstalled painted pilot bust
• Fuel Tank: 9.1oz (270cc)
• Landing Gear: Left and right aluminum sections 0.12" (3mm) thick
• Wheels: Main, foam 3" (76mm) diameter, tailwheel 0.87" (22mm) diameter
• Wheel Pants: Painted fiberglass
• Spinner: Plastic, red in color 2.5" (63mm) diameter
• Engine Mount: Two-piece composite
• Motor Mount: Plywood
• Warranty: Great Planes Model Manufacturing Company guarantees this kit to be free from defects in both materials and workmanship at the date of purchase.

Includes:

Great Planes Escapade Sport Airplane, landing gear, wheels, motor mount, engine mount, fuel tank, spinner, landing gear, pilot bust and instruction manual

Requires:

Radio: 4-channel
Servos: 3-5 standard size
Engine .40 - .55 cu in (6.5 - 9.0cc) 2-stroke glow OR .52 - .70 cu in (8.5 - 11.5cc) 4-stroke glow OR
Electric Motor: .46 RimFire (42-60-800kV)
Battery: 18.5V (5S) 3200mAh (or higher)LiPO (if using electric motor)
Electronic Speed Control: 60 amp (if using electric motor)
Charger: LiPo compatible charger and cell balancer (if using electric motor)
6" (152mm) Servo Extension: Two for single servo aileron control
Dual Servo Extension required for dual servo aileron control
1/4" foam rubber padding, propeller, building and field equipment

Technical Specifications:

Wingspan: 52.5" (1340mm)
Wing Area: 483 sq in (31.2 sq dm)
Weight: 5.0 - 5.5lb (2270 - 2495g)
Wing Loading: 24 - 26 oz/sq ft (73 - 80 g/sq dm)
Length: 46" (1160mm)
Airfoil: Semi-symmetrical, low wing configuration
Center of Gravity: 2-1/2" (63mm) Back from the wing's leading edge at the fuselage sides.
Control Throws- Low Rate High Rate
Ailerons: Up & Down 1/4" (6mm) 11° 1/2" (13mm) 22°
Elevator: Up & Down 3/4" (19mm) 15° 1-1/4" (32mm) 25°
Rudder: Right & Left 1-1/4" (32mm) 17° 2" (51mm) 26°
